Digital signage panel Samsung BE43FX-H 43″ LED 4K Ultra HD 3840 x 2160

The Samsung BE43FX-H is a 43″ LED digital signage panel with 4K Ultra HD resolution (3840 x 2160). Designed for commercial use, it supports up to 16 hours of operation per day and runs on the Tizen operating system. The panel includes built-in Wi‑Fi, Ethernet connectivity and integrated 20 W speakers for straightforward content playback and networked management.

Vorteile

The display delivers sharp 4K images on a 43″ LED screen with HDR10+ support for improved contrast and colour detail. Network features such as Ethernet and Wi‑Fi enable remote content updates and centralized control, while the durable design and continuous-operation rating make it suitable for retail, hospitality and corporate signage. Integrated speakers simplify installation by reducing the need for external audio equipment.

Geeignet für

• Retail shop windows and in-store promotions
• Reception areas and corporate lobbies
• Restaurants and cafes for menu boards
• Information displays in public spaces and transportation hubs

Wichtige technische Daten

• Model: Samsung BE43FX-H (LH43BEFHLGUXEN)
• Display diagonal: 43″ (107.9 cm)
• Resolution: 3840 x 2160 (4K Ultra HD)
• Display technology: LED
• HDR: HDR10+ support
• Operating system: Tizen
• Connectivity: Ethernet LAN, Wi‑Fi
• Built-in speakers: 20 W
• Colour: Black
• Energy class (SDR/HDR): G / G
• Energy consumption per 1000 h: 52 kWh (SDR) / 102 kWh (HDR)

Anleitung

Install the panel on a stable mount or stand following the manufacturer’s instructions and connect it to power. Use Ethernet or Wi‑Fi to link the display to your network, then manage content through the Tizen-based content management system or compatible signage software. Adjust display settings, schedule playlists and upload media files via network connection. For audio, use the built-in 20 W speakers or connect external audio if higher output is required.

Anwendungsempfehlungen

Place the panel in a location with adequate ventilation and avoid direct sunlight on the screen to maintain image quality. For continuous operation, verify network stability and schedule regular software updates and content checks to ensure reliable playback.
